Unencoded Variable Box Temp

VBSvariable-box-processingVBS002Updated Aug 03, 2025Archived Aug 03, 2025

✅Functional

Authors:vincent77777777777777777777insto

Endorsed by:Andrews54757

←→

1 / 2

View

Stores a partial box until another partial box with the same item type is input, after which both are output for merging. Despite being an unencoded system, this device is capable of quick access using a CUDDefinition: A Comparator Update Detector is based on the behavior inherent to comparators where they don't notice inventory changes when reading it through a solid block (including an inventory being moved awa... based integrated variable "encoderDefinition: An Encoder has two main meanings in storage tech: A contraption that translates items into a code, where code can be any sort of signal in any base (bin, hex, other less used ones) or other codes (...."

Features

• Up to 312 item types, 26 types in 12 sliceDefinition: A repeatable ( Preferably tileable ) component within a system.s.
• Uses CUDs and a built in variable encoder-like device to quickly identify slices storing a specific type. Takes only 70gtDefinition: Minecraft iteratively runs its processing code in a loop. One cycle of this loop is called a Tick or Gametick (gt). Gameticks are also used as the default measurement of time while working with re... to insert a box if no match is found.
• Even distribution of boxes across slices during initial filling. Afterwards, boxes are put in from furthest to closest slice to the input.
• Automatic ejection of overflow when there is no more capacity.
• Built-in item alignerDefinition: It aligns items within a block to ensure some sort of behavior. More basic concepts involve simply letting items in a water or ice stream hit against a block with a certain hitbox, while more compl... for direct input into mergerDefinition: A Merger is a contraption that takes 2 boxes as input, and merges them into one. Mergers can work of mixed boxes, however most mergers assume that both boxes only contain one itemtype and are ofte...s
• Pauseable

Considerations

• If a matching item type box is stored, the boxes in a matched slice are cycled through a variable box filter which can take up to 8*26 = 208 gt extra.
• Expanding the design to store more item types is not straightforward

Notes

Press the wooden button to start processing input. Flip the lever on the yellow concrete block to pause the system. Can theoretically work in Minecraft 1.16+
