Archive Entry

10x Shulker Box Loader

MLmixed-loadersML008Updated Dec 30, 2025Archived Dec 30, 2025

⁉️Untested

Authors:pearlasium

Endorsed by:Andrews54757

←→

1 / 2

View

A proof of concept (read: not recommended for real systems) high-speed shulker box loaderDefinition: A contraption that fills a shulkerbox with items and then breaks the shulkerbox. that operates at 10x hopper speedDefinition: Refers to the speed at which items are processed in a hopper (1 item every 8gt, or 2.5 items per second). Usually written as an integer (e.g. '3x hopper speed'). ## Common hopperspeeds 1x: 9000 ite... by breaking the box using duped TNT.

Features

• Loads boxes at 10x hopper speed
• Utilizes explosions traveling through corner gaps between diagonal blocks for obsidian shielding
• TNT raised on water-logged fence/wall to avoid hitting the top dropper
• Shulker box protects the bottom dropper from blast damage
• Two versions: one activates TNT only when the box is filled (slower box swapping), the main one pre-emptively launches TNT and blocks sight to the box until needed

Considerations

• Uses TNT to break the boxes
• Effective loading speed is 9.8x due to waiting for backlog detection and TNT breaking

Notes

Reddit post: https://www.reddit.com/r/redstone/comments/t4090t/10x_hopper_speed_shulker_box_loader/
