Stack Separation Sorter-Loader v3

HShigh-speed-sortingHS001Updated Jan 05, 2026Archived Jun 24, 2025

💔Broken

Authors:KikuGie

Endorsed by:Andrews54757

View

Uses stack separation to filter entire stack of items at once. Each of the 3wt modules loads sorted items into shulker boxes at 8xDefinition: Refers to the speed at which items are processed in a hopper (1 item every 8gt, or 2.5 items per second). Usually written as an integer (e.g. '3x hopper speed'). ## Common hopperspeeds 1x: 9000 ite... hopperspeed.

Features

• 8830 stacks/h core (up to 565k items/hr)
• 72k/h loaderDefinition: A contraption that fills a shulkerbox with items and then breaks the shulkerbox.s per sliceDefinition: A repeatable ( Preferably tileable ) component within a system.
• Distributive loading functionality
• Pause on slice overflow
• Partial box collectionDefinition: Typically reliable collection of a box during either unloading or box displays where you can grab items out of a box, and have it break the box for other use

Considerations

• Doesn't include storage and unsorted handling.
• Loaders can spit items

Notes

If you want to use multiple slices to load same item type, use 'multi-slice-loading-slice', with last in line being normal 'base' slice. Additional credits: RaPsCaLLioN1138 for stacksep core, camphorwood for 3wt 8x loader.
