Small 1wt N-pulse Clocks

CCclocks-and-countersCC006Updated Dec 28, 2025Archived Dec 28, 2025

✅Functional

Authors:FlutterDart

Endorsed by:Andrews54757

←→

1 / 4

View

Some 1wtDefinition: Annotates the width of a slice, and whether or not you can build them right next to each other. There are systems that are 1 wide, but you can't put 2 next to each other due to Crosstalk, so they d... clocks that can be configured to output different numbers of pulses. These can for example be used as 27 pulse clocks.

Variants

• Top activated (both even- and odd-n outputs)
• Top activated with comparator output for reset (only odd-n output)
• Bottom activated (only odd-n output)
• Side activated (only even-n output)

Features

• 1 Wide tileable
• Can be adjusted to many different pulse outputs

Considerations

• You need to wait until the hopper is empty before re-activating the clock
